Product Introduction

Measurement Specification

• Wind Speed Range : 4.1 to 100.0 m/s ±1%FS
• Pressure Range : ±200 mbar ±2%FS
• Wind Speed Unit Options : m/s, Km/h, mph, knot, ft/min
• Pressure Unit Options : mbar, psi, kg/cm², mm/Hg, inch/Hg, hPA, KPA, meter/H2O, inch/H2O, Atmosphere
• Display Screen : Large LCD with green backlight (ON/OFF)
• Air Velocity Range : m/s: 4.1 to 100.0, km/h: 14.7 to 360.0, mile/h: 9.1 to 223.7, knots: 7.9 to 194.3, ft/min: 81 to 19,685
• Air Velocity Resolution : m/s and km/h: 0.1, mile/h and knots: 0.1, ft/min: 1
• Air Velocity Precision : ±(3% + a)
• Pressure Units : mbar, psi, Kg/cm², mm Hg, inch Hg, meter H₂O, hPa, kPa, inch H₂O, Atmosphere
• Pressure Range : mbar: ±200, psi: ±2.9, Kg/cm²: ±0.204, mm Hg: ±150, inch Hg: ±5.905, meter H₂O: ±2.040, hPa: ±200, kPa: ±20, inch H₂O: ±80.2, Atmosphere: ±0.197
• Pressure Resolution : 1 mbar, 0 psi, 0 Kg/cm², 1 mm Hg, 0 inch Hg, 0 meter H₂O, 1 hPa, 0 kPa, 0 inch H₂O, 0.001 Atmosphere
• Pressure Precision : ±2% F.S.

Product Features

• Data Recording : Data can be downloaded to Excel for graph analysis
• Max/Min Value Recording : Supports max, min, and value lock functions
• Transmission Interface : RS-232 / USB output interface
• Data Logger Automatic Interval : 1 second to 8 hours 59 minutes 59 seconds
• Data Logger Manual Mode : Push the data logger button once to save data
• SD Card Capacity : 1 GB to 16 GB

Product Information

• Power Supply : DC 1.5V (AA) battery x 6
• Operating Environment : Temperature 0 to 50°C, Humidity less than 85% RH
• Power Consumption : Approx. DC 7 mA during normal operation, approx. DC 25 mA with SD card save data and LCD backlight OFF, additional approx. DC 10 mA with LCD backlight ON
• Dimensions : 190 x 68 x 45 mm (7.5 x 2.7 x 1.8 inches)
• Accessories : Instruction Manual x1, Quick Coupler Plugs x2, Pitot Tube (018) x1, Silicone Soft Tube (50 cm) x2
• Weight : 265 g
