By Brands

TE

Category: Thermal Monoculars
SKU: TE
The TE Series Handheld Thermal Imaging Monocular is a pocket-sized night vision powerhouse, offering exceptional performance at an affordable price. It is equipped with a highly sensitive infrared detector, providing multiple resolutions and lens options to meet your diverse needs in various environments. A 10-minute quick charge gives you an hour of continuous use, making it the perfect companion for your outdoor explorations.

Powerful 12μm detectorSharp image quality

To achieve a crisp image clarity, the TE Series is equipped with a powerful 12μm detector and offers multiple resolutions and lenses to meet your needs in various scenarios and activities.

Ultra-lightweightEffortlessly portable

The TE Series only weighs over 200 grams with a compact, pocket-sized design, small like a mobile phone and thinner than a wristwatch, offering a comfortable grip and exceptional portability.

Smooth operationOne-button, one-ring

Based on years of outdoor experience, the TE Series has streamlined the button design to simplify operations. With a one-button and one-ring design, you can easily access the menu and perform various functions, allowing for seamless control.

Extended battery20W quick charge

The TE Series integrates a built-in rechargeable battery that provides up to 6 hours of runtime. It features an advanced 20W quick charge function. With just 10-minute quick charging, you can enjoy 1 hour of continuous use, ensuring worry-free power.

Comfortable viewingClear and smooth visuals

The 0.32-inch AMOLED screen presents rich colors and clear, smooth images, offering top-notch visual effects. The comfortable eyepiece and 25mm eye relief reduce eye fatigue, providing a great visual experience for your outdoor observation activities.

Photos, videos, and audio recordings are all available. With 16GB built-in storage, you can flexibly capture and share exciting moments in the wild anytime and anywhere.

Dual-bandWiFi connection

The WiFi function has been upgraded to dual-band, providing stronger connectivity. The TE Series features faster transmission speeds and longer distances, with upgrade packages downloading in just 10 seconds and a maximum transmission distance of 26.5 meters.

Specifications

SpecificationTE210STE419STE425STE210MS
Product ModelTE210STE419STE425STE210MS
Sensor
Core technologyEquipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm Hyper-Light 2.0Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm Hyper-Light 2.0Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm Hyper-Light 2.0Equipped with full ApexVision S1 system architecture: Detector ApexCore S1 + Platform Nexus 1.0 + Algorithm Hyper-Light 2.0
TypeUncooled VOx Infrared Detector, 8 to 14µmUncooled VOx Infrared Detector, 8 to 14µmUncooled VOx Infrared Detector, 8 to 14µmUncooled VOx Infrared Detector, 8 to 14µm
Resolution256×192@12µm400×300@12µm400×300@12µm256×192@12µm
NETD15mK15mK15mK15mK
Frame rate50Hz50Hz50Hz50Hz
Lens
Objective lens10mm, F1.019mm, F1.025mm, F0.910mm, F1.0
Field of View17.5°×13.1°14.4°×10.8°11.0°×8.2°13.1°×13.1°
FOV m@100m31×2325×1919×1423×23
Magnification1.2x~4.8x1.4x~5.6x1.9x~7.6x0.4x~1.6x
Detection range500m/550yd1000m/1090yd1300m/1400yd500m/550yd
FocusFocus-freeManualManualFocus-free
Display
Display type0.32'' AMOLED 800×6000.32'' AMOLED 800×6000.32'' AMOLED 800×600Touch screen, 1.43'' AMOLED 466×466
Color palettesWhite Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, SepiaWhite Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, SepiaWhite Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, SepiaWhite Hot, Black Hot, Red Hot, Green Hot, Iron Red, Blue Hot, Sepia
EyepieceEye relief: 25mm; Diopter: -5 to +5; Zoom: 13.8xEye relief: 25mm; Diopter: -5 to +5; Zoom: 13.8xEye relief: 25mm; Diopter: -5 to +5; Zoom: 13.8x
Hardware
Wi-Fi2.4G, 5G2.4G, 5G2.4G, 5G2.4G, 5G
InterfaceUSB-C (Charging/Power supply/USB2.0)USB-C (Charging/Power supply/USB2.0)USB-C (Charging/Power supply/USB2.0)USB-C (Charging/Power supply/USB2.0)
OthersMicrophone, BluetoothMicrophone, BluetoothMicrophone, BluetoothMicrophone, Bluetooth
System
Recording functionPhoto/Video (Audio recording included)Photo/Video (Audio recording included)Photo/Video (Audio recording included)Photo/Video (Audio recording included)
Storage capacity64 GB64 GB64 GB64 GB
Power
Battery typeBuilt-in BatteryBuilt-in BatteryBuilt-in BatteryBuilt-in Battery
Operating time6 hours (Support 20W quick charging)5 hours (Support 20W quick charging)5 hours (Support 20W quick charging)6 hours (Support 20W quick charging)
Environmental
Operating temp.-20°C to 50°C / -4°F to +122°F-20°C to 50°C / -4°F to +122°F-20°C to 50°C / -4°F to +122°F-20°C to 50°C / -4°F to +122°F
IP RatingIP67IP67IP67IP67
Physical
Weight (g/oz)228/8.04288/10.16320/11.29200/7.05
Size (mm/in)47×47×132/1.85×1.85×5.2047×47×148/1.85×1.85×5.83157×51×47/6.18×2.01×1.8549×49×111/1.93×1.93×4.37
StandardDevice, Wrist Strap, Carry Bag, Lint-Free Cloth, USB-A to USB-C Cable, Quick Start Guide, Warranty CardDevice, Wrist Strap, Carry Bag, Lint-Free Cloth, USB-C to USB-C Cable, Quick Start Guide, Warranty CardDevice, Wrist Strap, Carry Bag, Lint-Free Cloth, USB-C to USB-C Cable, Quick Start Guide, Warranty CardDevice, Wrist Strap, Carry Bag, Lint-Free Cloth, USB-A to USB-C Cable, Quick Start Guide, Warranty Card
OptionalBluetooth Remote Control, Quick Charging Adapter, USB-C to USB-C CableBluetooth Remote Control, Quick Charging Adapter, USB-A to USB-C CableBluetooth Remote Control, Quick Charging Adapter, USB-A to USB-C CableBluetooth Remote Control, Quick Charging Adapter, USB-C to USB-C Cable
