l Resistance Measurement (4-wire).
l 10A (2mΩ, 20 mΩ) maximum test current.
l Best resolution 0.1μΩ.
l Basic accuracy 0.1%.
l Can work with many kinds of testing leads: Kelvin clip test leads, Double prod test leads, Alligator clip test leads.
l Warning function with Buzzer alarm.
l HI-LO LIMITS test function, judgment display PASS or FAIL.
l Reading HOLD function.
l Zero-adjustment function.
l Measurement mode of △ EMF eliminates thermal electromotive force.
l 4 1/2 digit liquid crystal display (LCD) with backlight (off) function.
l Battery charging function, battery level display.
l All kinds of low resistance (wire) measurement, contact resistance measurement, etc.
l With protection device to prevent live measurement of the DUT (Device Under Test), and protection from insufficient or excessive current.
l Automatic temperature control to start the fan cooling device.
l Ultra-large capacity lithium battery 7000mA/H.
Electrical Specifications: (23+/- 5℃)
(The total internal resistance of the test leads shall not exceed 200mΩ.)
RESISTANCE measurement:
|
Range |
Resolution |
Accuracy |
|
|
10A
2mΩ |
0.0000~2.0000mΩ |
0.1μΩ |
±0.15%±1.0μΩ |
|
10A
20mΩ |
0.000~20.000mΩ |
1μΩ |
±0.1%±3μΩ |
|
1A
200mΩ |
0.00~200.00mΩ |
10μΩ |
±0.1%+30μΩ |
|
100mA
2000mΩ |
0.0~2000.0mΩ |
100μΩ |
±0.1%+300μΩ |
|
10mA
20Ω |
0.000~20.000Ω |
1mΩ |
±0.1%+3mΩ |
|
1mA
200Ω |
0.00~200.00Ω |
10mΩ |
±0.1%+30mΩ |
|
100μA
2000Ω |
0.0~2000.0Ω |
100mΩ |
±0.1%+300mΩ |
General Specifications:
|
Power Source: |
Rechargeable Lithium Battery
7000mAh (11.1V) |
|
Battery Recharging Time: |
8 hours |
|
AC adaptor: (for Battery Charging only) |
AC 110V / 220V input
DC 15V / 4A output (Please note that DC is positive inside and negative outside.) |
|
LCD Display: |
4 1/2 Digit LCD + Backlight |
|
Dimension: |
257 (L) x 155 (W) x 57 (H) mm |
|
Weight: |
1340g / 47.3oz (Battey included) |
|
Operation Environment: |
0℃ ~ 50℃, ≤85% RH |
|
Storage Environment: |
-20℃ ~ 60℃, ≤75% RH |
|
Standard Accessories: |
Rechargeable Lithium Battery x 1
AC adaptor x 1
User Manual x 1
Kelvin clip test leads x 1 set
Kelvin alligator clip test leads x 1 set
4-wire double prod test leads x 1 set
Alligator clips (black & red) test leads x 2 sets |
