Magnetic Stirrer PCE-MSR 10

Category: Magnetic Stirrer
Magnetic Stirrer for liquids up to 5 litres / Stirring speed up to 1600 rpm / 1 stirring position / Stirring plate - acrylic glass / Compact

The Magnetic Stirrer is a compact and powerful laboratory device for the efficient mixing of liquids. With an adjustable stirring speed of 200 to 1600 rpm, it is ideal for volumes of up to 5 liters. The robust stirring plate made of acrylic glass with dimensions of 173 × 180 mm provides a stable work surface.

The Magnetic Stirrer is driven by a brushless motor, which guarantees particularly quiet and low-maintenance operation. The stirring rod supplied measures 8 mm in diameter and is 30 mm long - ideal for a wide range of everyday laboratory applications. With a power consumption of just 10 watts, the Magnetic Stirrer is also extremely energy-efficient. Power is supplied flexibly via 100 to 240V AC at 50/60 Hz.

Typical areas of application are chemical and biological laboratories, research facilities and industrial processes where reliable and uniform mixing is required.

Highlights

- Stirring speed adjustable from 200 ... 1600 rpm adjustable
- Stirring plate made of acrylic glass
- for a maximum of 5 litres of liquid
- Power supply: 100 ... 240V AC, 50/60 Hz

Specification

General technical data
Dimensions   Stirring plate: 173 x 180 mm
Stirring rod: Ø 8 x 30 mm
Performance   10 W
Number of stirring points   1
Drive of the stirring points   Brushless motor
Max. Stirring quantity   5 l
Stirring plate material   Acrylic glass
Adjustable speed   200 ... 1600 rpm
Protection class (device)   IP42
Power supply   100 ... 240 V AC | 50/60 Hz
Connector type   Cold-device plug
Operating conditions   0 ... 50 °C , 0 ... 80 % RH
Storage conditions   0 ... 50 °C , 0 ... 80 % RH
Dimensions ( L x W x H )   270 x 180 x 50 mm
Weight   1060 g
